PGL-B喷雾干燥制粒机(一步机)

PGL-B喷雾干燥制粒机(一步机)

喷雾干燥制粒机适用于中成药制备冲剂、胶囊、片剂颗粒或对颗粒进行包衣。

详细说明

应用概述 General of applications

★喷雾干燥制粒机适用于中成药制备冲剂、胶囊、片剂颗粒或对颗粒进行包衣。

★PGL machine is suitable for Chinese traditional medicine granule, such as capsule and tablet or coating of granule.


设备特点 Features of equipment

★多流体雾化器,更适用于多糖成分,粘稠性强或热敏性的产品。

★喷雾干燥室、捕集室、流化床及二次供风系统等结构进行了重要的修改后,更加贴切的表现出喷雾干燥的特性。

★按照“GMP”要求进行设计、制造及布局。

★实现连续的浸膏喷雾过程。

★操作简便、可靠

★提高喷雾干燥效率。

★比FL型流化更为稳定,提高了流化干燥强度,克服了“死床”现象。

★Multi-fluid atomizer. Particularly it is suitable for material that contains component of amylase and has strong viscosity or theral sensitive product.

★The structure of spraying drying chamber, filtering chamber, fluid-bed and secondary air supply system has been improved greatly. It can appear the features of spraying drying deeply.

★Designed and manufactured laid out by GMP

★Can realize continuous spraying process of immersed paste.

★Simple and reliable operation

★Improve spraying and drying efficiency

★Compared with FL, the fluid-bed is more constant and the adjusted air amount is more reasonable. The drying degree is improved and the “dead bed” is overcomed.



项目 ltem 规格 Specification

3

5

10

20

30

40

80

120

150

原料容器容积

Container volume

L

26

50

100

220

300

420

670

1000

1500

供液量

Liquid speed

kg/h

2-4

4-6

6-15

15-25

20-40

30-60

60-100

20-160

100-200

液体比重

Specific gravity of liquid

kg/L

≤1.3

蒸汽

Steam

压强

Pressure

Mpa

0.4-0.6

耗量

Consumption

Kg/h

25

50

120

160

240

280

300

380

465

压缩空气

Compressed air

压强

Pressure

Mpa

0.6

耗量

Consumption

m3/min

0.4

0.6

0.9

0.9

1.1

1.1

1.3

1.6

1.8

辅助鼓风机功率

Auxiliary blower fan

Kw

0.55

0.75

0.75

1.1

1.5

1.5

1.5

2.2

2.2

引风机功率

Power

Kw

3

4

7.5

11

18.5

18.5

22

30

37

主机尺寸

Installation size for reference

H1(mm)

1900

2360

2680

3150

3630

3630

4120

5050

5400

H2(mm)

190

260

340

490

540

590

690

890

990

H3(mm)

1680

2140

2460

2930

3410

3410

3900

4830

5180

Ø1(mm)

400

550

700

1000

1100

1200

1400

1800

2000

Ø2(mm)

150

180

180

250

280

280

315

355

355

B(mm)

860

1010

1160

1460

1560

1660

1860

2260

2460

L(mm)

1050

1050

1250

1400

1450

1500

1600

1800

2000



所有参数仅作参考,视物料情况,本公司拥有变更权利,并不另行通知。

All datas are used for reference only. According to the condition of material, our factory has the right to change but not notice, pardon!
